Engineered for professionals, educators, and small shops, the Axiom 2x2 CNC Router delivers industrial-grade performance without demanding industrial space. With superior accuracy, repeatability, and speed, this compact powerhouse is built to elevate your craft.

Whether you're scaling up production, inspiring future makers, or diving into CNC for the first time, the Axiom 2x2 delivers the precision, power, and reliability you need—without compromise.

Features:

24" x 24" cutting area with 5.5" Z-axis travel
±0.007" accuracy with precision ball screws on all axes
Rigid all-metal frame and extruded aluminum gantry
1-HP air-cooled spindle with speeds up to 24,000 RPM
Prismatic linear guides for smooth, repeatable motion
Includes UCCNC software and Vectric VCarve Desktop software (Windows Compatible)
Backed by Axiom’s expert U.S.-based support and service team

Specifications:

Assembled Dimensions: 31.5" x 36" x 31.5"
Cutterhead Speed: Up to 24000 rpm
Motor: 1 HP, 5A
Input Power: 115V Single Phase
Motor Voltage: 220V
Collet: 1/8" and 1/4"
Spindle Taper: ER11
Table Length: 24"
Table Width: 24"
X-Axis Travel: 24"
Y-Axis Travel: 24"
Z-Axis Travel: 5.5"

What's Included:

2x2 CNC Router Model AX1-101
Access Accessories Kit (open wrench, chuck, puck, pads, power cord, etc)
Spindle
Leveling Pad (set of 4)
7 Board Set (5) 80mm boards, (2) 65mm boards
Amana ER11 Spring Collet 1/4
Amana ER11 Spring Collet 1/8
RJ45 Ethernet cable

Shipping / Billing Information

This product ships direct from the manufacturer:

Your order will ship in approximately 2-4 business days.
This product is considered special order. Your account will be charged when you place your order.
Express or overnight shipping is not available for this product.
Ships by Ground to the 48 contiguous states. Cannot ship to Alaska, Hawaii, PO Boxes, APOs, US Territories, Canada or other foreign countries.

Return Information

All customer returns, excepting defects, are subject to a 20% restocking fee. If you need help intiating a return, please contact Woodcraft Customer Service at 1-800-535-4482.

Warranty Information

Axiom Tool Group warrants their products to be free from defects in materials and workmanship for a period of 1 year. If you have a warranty inquiry, please contact Axiom Tool Group at 844-642-4902.
Free Technical Support direct from Axiom
